China supplier Vertical high efficiency food grade silo grain bucket elevator for sale

FOB Reference Price:Get Latest Price
$1,000.00 - $15,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
grain bucket elevator
Material:
Stainless Steel
Material Feature:
Heat Resistant
Structure:
Conveyor System
Load Capacity:
15~480t/m3
Place of Origin:
Hubei, China
Brand Name:
YIJI
Model Number:
TZD200~1000
Voltage:
220V/380V
Power(W):
1.5~160kw
Dimension(L*W*H):
Specific Models
Certification:
ISO,TUV
Conveying capacity:
10~800t/h
Casing material:
stainless steel
Bucket volume:
1.21~20L
Bucket distance:
105~300mm
Belt width:
200~1000mm
Bucket speed:
1.76~3.94 m/s
Application:
grain industry
Bucket catelogy:
food grade silo grain bucket elevator
Color:
Customers' Requirement
Product name:
grain bucket elevator
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
120 Set/Sets per Month
Packaging & Delivery
Packaging Details
Export packing (Wooden cas ,carbon case or pallet).It is suitable for long distance ocean transportation.
Port
Shanghai, Tianjin, Qingdao
Lead Time :
Shipped in 10 days after payment
Product Description

China supplier Vertical high efficiency food grade silo grain bucket elevator for sale


Specifications

1.Food grade grain bucket elevator with Rectangular DOUBLE CHANNEL closed case.
2. Flanged structure and bolt connection.
3. Large lifting capacity.
4. ISO,TUV, SEW,FLENDER.

Operating principle

When the driving device of Food grade grain bucket elevator start working , it drives the puley to make the belt with plastic buckets to do the circular movement from the below of the tail to the top of the head The head section has outlet and the tail section has inlet.
The Food grade grain bucket elevator is filled with material and run to the head section, then the material is thrown out from the outlet under the action of centrifugal force according to the parabolic design.With the running, the empty bucket is back to the below tail section and be filled material from the inlet again,then be lifted up to do parabolic discharge movement . So this cycle finish the vertical transport of materials.

Application scope

Food grade grain bucket elevator is widely used in grain and oil, metallurgy, cement, chemical, light industry and so on. It is used for lifting rice, grain ,wheat, piece coal, crushed stone, mineral stone, egg stone, dry and bulk and fluidity power, granular and block material and so on. The material density is not more than 2 t/m3, the site temperature is not more than 2500C.

Technical Parameter of Food grade grain bucket elevator

Type
TZD200
TZD250
TZD300
TZD400
TZD500
TZD650
TZD800
TZD1000
Belt width(mm)
200
250
315
400
500
650
800
1000
Bucket Capacity (L)
1.21
2.35
3.1
6.1
11.5
2*3.1
2*6.1
2*11.5
Bucket pitch(mm)
105-300
125-150
145
195
255
145
195
255
Belt speed (m/s)
1.76-2.75
1.76-3
1.93-3.05
1.93-3.05
1.97-3.1
2.2-3.87
2.5-3.94
2.5-3.94
Capacity (t/h)
10-50
30-100
50-150
80-150
100-200
150-300
200-400
400-600
Max lifting height (m)
60
60
65
65
65
65
65
65

Main Features

1.Food grade grain bucket elevator need small installation space and can lift more materials. it can convey the grain, for example wheat, soybean , corn etc.
2.The transmission capacity is large, it is up to 800 t/h.
3.The belt with the plastic buckets .
4.Long use life.
Certifications
Detailed Images

Machine Parts

Name: Plastic bucket

Brand: YIJI

Original: China

Plastic bucket can provide high density polyethylene, nylon, polyurethane three materials.With high strength, corrosion, resistance, smooth surface, in line with the national food installation standards.Light weight, prolong the service life of the lifting belt.Toughness is good, the material crushing rate is low.

Main Features

Name: Lifting Belt
Brand: YIJI
Original: China
Lifting belt with cotton canvas, nylon and polyester three knids of materials.

According to the different use of the environment, lifting belt is divided into ordinary, heat, cold, acid and alkali resistance, oil resistance, food conveyor belt and other models.

Machine Parts

Name: Head section
Brand: YIJI

Original: China

The head section comprises head roller, bearing assembly, discharge port, observation door, blocking alarm and so on.

After the material is raised, discharge at the discharge port at the head.

Main Features

Name: Middle section
Brand: YIJI

Original: China
The middle casing is finished by the plasma cutting machine, shape rules, high precision. Bucket elevator has a good sealing performance with the rectangular closed casing, no leakage in the conveying process.The segments are connected by bolts, using the sealing gasket and sealant to seal.

Name: Tail section
Brand: YIJI
Original: China

The tail section comprises tail roller, bearing assembly, inlet port, observation door, speed sensor and so on.
The material is added at the tail inlet,then to be promoted.
Speed sensor is installed on the shaft of tail and used to detect the speed of equipment whether it is normal, and convey the signal  to the electronic control system.

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Packaging
Size
600(L) * 300 (W) * 270 (D)
Weight
10T



Packaging Details
The closed package is iron box(Size: L*W*H).
Use the iron box to pack the parts that need to be protected, such as electric motors, speed reducer, electrical control equipment and so on. We also can packe it according to customers special request.
Packaging
Size
600(L) * 300 (W) * 270 (D)
Weight
10T



Packaging Details
The Non standard package is iron frame(Size: L*W*H).
We use the iron frame to package some overall and larger components, such as the head, tail, middle section. We can pack it according to customers special request.
