Grain silo Convey system Drag Chain Conveyor for Sale

FOB Reference Price:Get Latest Price
$2,000.00 - $8,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
chain conveyor
Material:
Carbon steel
Material Feature:
Heat Resistant
Structure:
chain conveyor
Load Capacity:
25~240t/h
Place of Origin:
Hubei, China
Brand Name:
YIJI
Model Number:
RMS25~RMS80
Voltage:
380v or customized
Power(W):
1.5~160kw
Dimension(L*W*H):
Specific Models
Certification:
ISO9001:2008
Trough width:
250/320/400/500/630/800
Chain speed:
0.2~0.32m/s
Transportation length:
0~80 m
Chute width:
250~800mm
Scraper chain type:
S30-DT,Z30-DT
Product name:
chain conveyor
Application:
crushed material
paint color:
as customer request
Structure design:
flange structure and bolt connection
conveyor name:
chain conveyor
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
120 Set/Sets per Month
Packaging & Delivery
Packaging Details
Export Packing(Wooden Case, Carbon Case and Pallet),it is suitable for long distance ocean transportation.
Port
Shanghai, Tianjin, Qingdao
Lead Time :
Shipped in 15 days after payment
Product Description

Grain silo Convey system Drag Chain Conveyor for Sale


Specification

1. The Nation Standard maker of chain conveyor.
2. WIth a large capacity.
3. Full-closed structure.
4. Conveyor length up to 80 m.
5. ISO,TUV, SEW, FLENDER.

Operating Principle

When chain conveyor is conveying materials, the pressure which comes from the chains in conveying direction of materials and the weight function of materials themselves cause the internal friction.This friction assures the stable condition between material layers, and it can overcome the external frictional which caused by moving materials in the trough,then make the materials to form a continuous whole flow to be transported.

Product Application

Chain conveyor has become a widely used equipment for bulk material transportation, it is widely used in metallurgy, building materials, electric power, chemical, cement, coal, port, wharf, mine, oil, food, feed and other industries.

Main Features

1. Chain conveyor with Simple structure ,easy in installation and maintation.
2.The heat resistant steel as the main parts make it handle high temperature big bulk density materials.
3. Running in a high automatization.
4. Can be loaded and unloaded on multiple points.

Detailed Images

Machine Parts

Name: Scraper chain

Brand: YIJI

Original: China

1. Chain link has a variety of pitch, fully meet the delivery of bulk materialss.
2. Take tempering, carburizing and other heat treatment, improve wear resistance.
3. High quality alloy steel material.(40Cr,20CrMnTi)
4. With high temperature resistance and high tensile strength.

Main Features

Name: Closed structure
Brand: YIJI
Original: China
Chain conveyor has a good sealing performance with the rectangular closed casing, no leakage in the conveying process.The segments are connected by bolts, using the sealing gasket and sealant to seal.

Machine Parts

Name: Head part
Brand: YIJI
Original: China
It includes wheel, shaft, bearing, bearing seat and so on. The wheel is composed of a wheel hub and a toothed plate, and the toothed plate can be replaced by a bolt, so that the maintenance is convenient.

Main Features

Name: Tail part
Brand: YIJI
Original: China
It includes wheel, shaft, bearing, bearing seat and so on, It has a crew thread tension and can adjust the length of scraper chains.The tail shaft is provided with a speed sensor, the sensor will obtain the speed signal to the control system, to achieve the function of security protection.

Certifications
Protection device

Plugging alarm device

Device Type: A059

Switch Type: Limit switch

It is installed on the end cover plate of the head. When the material height exceeds the set value, the alarm signal is sent out to control the height of the material layer.(See red part in the picture.)

Speed Sensor

Device Type: A032
Switch Type: Proximity switch
 It is installed in the tail of the tail shaft and tail shaft to rotate together. When the speed exceeds the set range, it transmits a signal to the control system, so as to control the start and the stop of the motor to protect the equipment operation.

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Packaging
Size
600(L) * 300 (W) * 270 (D)
Weight
10T



Packaging Details

The closed package is iron box(Size: L*W*H).

Use the iron box to pack the parts that need to be protected, such as electric motors, speed reducer, electrical control equipment and so on. We also can packe it according to customers special request.

Packaging
Size
600(L) * 300 (W) * 270 (D)
Weight
10T



Packaging Details
The Non standard package is iron frame(Size: L*W*H).
We use the iron frame to package some overall and larger components, such as the head, tail, middle section. We can pack it according to customers special request.
